Design of Metal-Insulate-Metal Plasmonic Waveguide Biosensor for Disease Diagnosis

Subject Areas : Optical Biosensors

Maryam Sharifi ¹ , Habib Tajalli ² , Mehri Pourasl ³

1 -
2 - Biophotonics Research Center,Tabriz Branch, Islamic Azad University
3 -

Received: 2024-11-22 Accepted : 2025-02-26 Published : 2025-03-28

Keywords: Biosensor, Fano Resonance, FEM, MIM waveguide,

Abstract :

A plasmonic metal-insulator-metal (MIM) biosensor exploits the optical properties of surface plasmon resonances (SPRs) to achieve high sensitivity and specificity in biomolecule detection. The MIM structure in this study features a narrow waveguide as the insulator layer, flanked by elliptical arrays of solid metallic ovals surrounded by thin air layers. These arrays generate localized surface plasmon polaritons, which enhance light-matter interaction. The system operates through dual plasmonic resonances, specifically Fano resonances, resulting in a distinct transmission spectrum. Numerical simulations using the finite element method confirm the sensor's ability to detect minor refractive index shifts, making it highly responsive to small biological variations The simulation results indicate that the proposed design can achieve a sensitivity of tens of picometers for a refractive index change as small as Δn=10⁻⁶. This MIM biosensor shows significant potential in applications such as point-of-care diagnostics and environmental monitoring. It can detect a wide range of biomolecules, including proteins, DNA, and pathogens, with high precision, enabling early disease detection and real-time monitoring of environmental contaminants. The enhanced sensitivity provided by Fano resonances positions this technology as a promising tool for personalized medicine, public health, and safety applications

References:

Zhang J, Zhang L, Xu W. Surface plasmon polaritons: physics and applications. Journal of Physics D: Applied Physics. 2012;45(11):113001.
2. Sharifi M, PASHAEI AH, Tajalli H, Bahrampour A. Design of surface plasmon resonance biosensor with one dimensional photonic crystal for detection of cancer. 2016.
3. Martínez J, Ródenas A, Aguiló M, Fernandez T, Solis J, Díaz F. Mid-infrared surface plasmon polariton chemical sensing on fiber-coupled ITO coated glass. Optics Letters. 2016;41(11):2493-6.
4. Gric T, Rafailov E. Propagation of surface plasmon polaritons at the interface of metal-free metamaterial with anisotropic semiconductor inclusions. Optik. 2022;254:168678.
5. Bai Y, Li Y, Ikram M, Ren Y, Xu Y, Wang Y, et al. Circular dichroism induced by the coupling between surface plasmon polaritons and localized surface plasmon resonances in a double-layer complementary nanostructure. The Journal of Physical Chemistry C. 2022;126(24):10159-66.
6. Zhang HC, Zhang LP, He PH, Xu J, Qian C, Garcia-Vidal FJ, et al. A plasmonic route for the integrated wireless communication of subdiffraction-limited signals. Light: Science & Applications. 2020;9(1):113.
7. Schröder B. Probing Light-Matter Interactions in Plasmonic Nanotips: Dissertation, Göttingen, Georg-August Universität, 2020; 2020.
8. Joseph S, Sarkar S, Joseph J. Grating-coupled surface plasmon-polariton sensing at a flat metal–analyte interface in a hybrid-configuration. ACS Applied Materials & Interfaces. 2020;12(41):46519-29.
9. Kumari S, Verma YK, Tripathi SM. Plasmonic Ring Resonator Sensor with High Figure of Merit and Sensitivity Using Degenerate N-Doped Silicon for SPP Excitation. Plasmonics. 2024:1-9.
10. Aminah NS, Lertvanithphol T, Sathukarn A, Horprathum M, Alatas H, Fauzia V, et al. Fabrication of Au coated sinusoidal grating substrates as SPP-SERS sensor chip for trace-level detection of explosive. Optical Materials. 2024;149:114952.
11. Chen H, Yan S, Cao Y, Jiang W, Yan X, Wang C, et al. Nanoscale temperature sensors based on MIM waveguide coupling and ring-embedded nanostructures. Frontiers in Physics. 2024;12:1456177.
12. Lu H, Wang G, Liu X. Manipulation of light in MIM plasmonic waveguide systems. Chinese Science Bulletin. 2013;58:3607-16.
13. Chen J, Li J, Liu X, Rohimah S, Tian H, Qi D. Fano resonance in a MIM waveguide with double symmetric rectangular stubs and its sensing characteristics. Optics communications. 2021;482:126563.
14. Sharifi M, Rezaei B, Pashaei Adl H, Zakerhamidi MS. Tunable Fano resonance in coupled topological one-dimensional photonic crystal heterostructure and defective photonic crystal. Journal of Applied Physics. 2023;133(8).
15. Adhikari R, Chauhan D, Mola GT, Dwivedi RP. A review of the current state-of-the-art in Fano resonance-based plasmonic metal-insulator-metal waveguides for sensing applications. Opto-Electronics Review. 2021;29.
16. Gai H, Wang J, Tian Q. Modified Debye model parameters of metals applicable for broadband calculations. Applied optics. 2007;46(12):2229-33.
