Stimuli-Responsive Poly(dimethylaminoethyl methacrylate) Nanogels Templated by Cellulose Nanocrystal Pickering Emulsions for Nitrate Removal

محورهای موضوعی : Applied Nanomaterials and smart polymers

Mojtaba Azizi ¹ , Milad Aghazadeh-Bonab ² , Seyed Mahdi Saedi ³ , Zeynab Emdadi ⁴

1 - Department of Chemistry, Iran University of Science and Technology, P.O. Box 1684613114, Tehran, Iran
2 - Department of Polymer Engineering and Color Technology, Amirkabir University of Technology, P.O. Box 15875-4413, Tehran, Iran
3 - Faculty of Industrial Engineering, Sharif University of Technology, Tehran, Iran
4 - Department of Chemistry, Iran University of Science and Technology, P.O. Box 1684613114, Tehran, Iran

تاریخ دریافت : 1404/08/09 تاریخ انتشار : 1404/11/15

کلید واژه: Pickering emulsion polymerization, pH-responsive PDMAEMA nanohydrogels, Cellulose nanocrystals, Nitrate adsorption, Smart polymers,

چکیده مقاله :

Elevated nitrate in groundwater and surface waters calls for efficient, regenerable adsorbents with low surfactant loading. Herein, pH-responsive poly(dimethylaminoethyl methacrylate)(PDMAEMA) nanohydrogels, using RAFT, through Pickering emulsion polymerization stabilized with cellulose nanocrystals grafted with amphiphilic poly(butylacrylate)-b-poly(dimethylaminoethyl methacrylate)(PBA-b-PDMAEMA), are reported. FT-IR confirmed the successful grafting, and the amphiphile gave a low critical micelle concentration (0.083 mg mL⁻¹), supporting robust interfacial activity. Dynamic light scattering/ζ-potential revealed that pH-dependent changes in size and charge were reversible, becoming more compact and cationic under acidic conditions. Such changes are consistent with protonation of the PDMAEMA. Under batch conditions, such as 500 ppm NO₃⁻ at pH 4, UV-Vis tracking shows rapid, steadily increasing nitrate uptake, evidencing strong electrostatic sorption within the protonated network. All these results establish a structure-function coupling of polymer charge state with anion capture and illustrate a modular route to regenerable adsorbents that avoids conventional surfactants. A readily tunable platform via the block composition and crosslink density shows promise for use in water remediation in continuous flow for nitrate and other anions.

چکیده انگلیسی:

Elevated nitrate in groundwater and surface waters calls for efficient, regenerable adsorbents with low surfactant loading. Herein, pH-responsive poly(dimethylaminoethyl methacrylate)(PDMAEMA) nanohydrogels, using RAFT, through Pickering emulsion polymerization stabilized with cellulose nanocrystals grafted with amphiphilic poly(butylacrylate)-b-poly(dimethylaminoethyl methacrylate)(PBA-b-PDMAEMA), are reported. FT-IR confirmed the successful grafting, and the amphiphile gave a low critical micelle concentration (0.083 mg mL⁻¹), supporting robust interfacial activity. Dynamic light scattering/ζ-potential revealed that pH-dependent changes in size and charge were reversible, becoming more compact and cationic under acidic conditions. Such changes are consistent with protonation of the PDMAEMA. Under batch conditions, such as 500 ppm NO₃⁻ at pH 4, UV-Vis tracking shows rapid, steadily increasing nitrate uptake, evidencing strong electrostatic sorption within the protonated network. All these results establish a structure-function coupling of polymer charge state with anion capture and illustrate a modular route to regenerable adsorbents that avoids conventional surfactants. A readily tunable platform via the block composition and crosslink density shows promise for use in water remediation in continuous flow for nitrate and other anions.

منابع و مأخذ:

[1] E. Abascal, L. Gómez-Coma, I. Ortiz, and A. Ortiz, “Global diagnosis of nitrate pollution in groundwater and review of removal technologies,” Sci. Total Environ., vol. 810, 2022, doi: 10.1016/j.scitotenv.2021.152233.
[2] T. N. Dharmapriya, H. Y. Shih, and P. J. Huang, “Facile Synthesis of Hydrogel-Based Ion-Exchange Resins for Nitrite/Nitrate Removal and Studies of Adsorption Behavior,” Polymers (Basel)., vol. 14, no. 7, 2022, doi: 10.3390/polym14071442.
[3] Z. Abousalman-Rezvani, H. Roghani-Mamaqani, H. Riazi, and O. Abousalman-Rezvani, “Water treatment using stimuli-responsive polymers,” Polym. Chem., vol. 13, no. 42, pp. 5940–5964, 2022, doi: 10.1039/d2py00992g.
[4] M. Sadeghi Afjeh, G. Bagheri Marandi, and M. J. Zohuriaan-Mehr, “Nitrate removal from aqueous solutions by adsorption onto hydrogel-rice husk biochar composite,” Water Environ. Res., vol. 92, no. 6, pp. 934–947, 2020, doi: 10.1002/wer.1288.
[5] Z. Yilmaz, P. K. Akkaş, M. Şen, and O. Güven, “Removal of nitrite ions from aqueous solutions by poly(N,N-dimethylamino ethylmethacrylate) hydrogels,” J. Appl. Polym. Sci., vol. 102, no. 6, pp. 6023–6027, 2006, doi: 10.1002/app.25206.
[6] L. Zhao, J. Sun, Y. Zhao, L. Xu, and M. Zhai, “Removal of hazardous metal ions from wastewater by radiation synthesized silica-graft-dimethylaminoethyl methacrylate adsorbent,” Chem. Eng. J., vol. 170, no. 1, pp. 162–169, 2011, doi: 10.1016/j.cej.2011.03.047.
[7] J. Li, S. Dong, Y. Wang, X. Dou, and H. Hao, “Nitrate removal from aqueous solutions by magnetic cationic hydrogel: Effect of electrostatic adsorption and mechanism,” J. Environ. Sci. (China), vol. 91, no. February, pp. 177–188, 2020, doi: 10.1016/j.jes.2020.01.029.
[8] Y. Tian, “Characterization of nitrate ions adsorption and diffusion in P(DMAEMA/HEMA) hydrogels,” Chinese Chem. Lett., vol. 19, no. 9, pp. 1111–1114, 2008, doi: 10.1016/j.cclet.2008.05.040.
[9] J. S. Karthika and B. Vishalakshi, “Novel stimuli responsive gellan gum-graft-poly(DMAEMA) hydrogel as adsorbent for anionic dye,” Int. J. Biol. Macromol., vol. 81, pp. 648–655, 2015, doi: 10.1016/j.ijbiomac.2015.08.064.
[10] S. Fujisawa, E. Togawa, and K. Kuroda, “Nanocellulose-Stabilized Pickering Emulsions and Their Applications,” Sci. Technol. Adv. Mater., vol. 18, no. 1, pp. 959–971, 2017, doi: 10.1080/14686996.2017.1401423.
[11] X. Ren, C. Zhou, A. Qayum, J. Tang, and Q. Liang, “Pickering emulsion: A multi-scale stabilization mechanism based on modified lotus root starch/xanthan gum nanoparticles,” Int. J. Biol. Macromol., vol. 233, no. February, p. 123459, 2023, doi: 10.1016/j.ijbiomac.2023.123459.
[12] W. Zheng et al., “Pickering emulsion hydrogel based on alginate-gellan gum with carboxymethyl chitosan as a pH-responsive controlled release delivery system,” Int. J. Biol. Macromol., vol. 216, no. July, pp. 850–859, 2022, doi: 10.1016/j.ijbiomac.2022.07.223.
[13] H. Zhao, Y. Yang, Y. Chen, J. Li, L. Wang, and C. Li, “A review of multiple Pickering emulsions: Solid stabilization, preparation, particle effect, and application,” Chem. Eng. Sci., vol. 248, p. 117085, 2022, doi: 10.1016/j.ces.2021.117085.
[14] Z. Tajmoradi, H. Roghani-Mamaqani, and M. Salami-Kalajahi, “Cellulose nanocrystal-grafted multi-responsive copolymers containing cleavable o-nitrobenzyl ester units for stimuli-stabilization of oil-in-water droplets,” Chem. Eng. J., vol. 417, p. 128005, 2021, doi: 10.1016/j.cej.2020.128005.
[15] D. Nguyen et al., “Janus particles by simplified RAFT-based emulsion polymerization process for polymer coating,” Colloid Polym. Sci., vol. 300, no. 4, pp. 341–349, 2022, doi: 10.1007/s00396-021-04939-x.
[16] L. Bai et al., “RAFT-mediated Pickering emulsion polymerization with cellulose nanocrystals grafted with random copolymer as stabilizer,” RSC Adv., vol. 8, no. 50, pp. 28660–28667, 2018, doi: 10.1039/c8ra03816c.
[17] J. Arredondo, N. M. Woodcock, O. Garcia-Valdez, P. G. Jessop, P. Champagne, and M. F. Cunningham, “Surface modification of cellulose nanocrystals via RAFT polymerization of CO2-responsive monomer-tuning hydrophobicity,” Langmuir, vol. 36, no. 46, pp. 13989–13997, 2020, doi: 10.1021/acs.langmuir.0c02509.
[18] Y. Bai, Y. N. Liang, and X. Hu, “An eco-friendly approach for heavy metal adsorbent regeneration using CO2-responsive molecular octopus,” Chemosphere, vol. 185, pp. 1157–1163, 2017, doi: 10.1016/j.chemosphere.2017.07.086.
[19] N. B. Tran, J. Y. Kim, Y. C. Kim, Y. J. Kim, and J. H. Kim, “CO2-responsive swelling behavior and metal-ion adsorption properties in novel histamine-conjugated polyaspartamide hydrogel,” J. Appl. Polym. Sci., vol. 133, no. 16, pp. 1–10, 2016, doi: 10.1002/app.43305.
[20] P. Lampman, K. Vyvyan, D. L. Pavia, and G. S. Kriz, Introduction to spectroscopy, 4th editio. 2009.
[21] B. Liu et al., “Hydrogen peroxide-responsive anticancer hyperbranched polymer micelles for enhanced cell apoptosis,” Polym. Chem., vol. 6, no. 18, pp. 3460–3471, 2015, doi: 10.1039/C5PY00257E.
[22] D. A. Christian, S. Cai, D. M. Bowen, Y. Kim, J. D. Pajerowski, and D. E. Discher, “Polymersome carriers: From self-assembly to siRNA and protein therapeutics,” Eur. J. Pharm. Biopharm., vol. 71, no. 3, pp. 463–474, 2009, doi: https://doi.org/10.1016/j.ejpb.2008.09.025.
[23] I. Kalashnikova, H. Bizot, B. Cathala, and I. Capron, “Modulation of Cellulose Nanocrystals Amphiphilic Properties to Stabilize Oil/Water Interface,” Biomacromolecules, vol. 13, pp. 267–275, 2012.
[24] L. Li, C. Zhang, R. Zhang, Z. Xu, Z. Xu, and A. K. Whittaker, “Multifunctional Magnetized Porous Silica Covered with Poly(2-dimethylaminoethyl methacrylate) for pH Controllable Drug Release and Magnetic Resonance Imaging,” ACS Appl. Nano Mater., vol. 1, no. 9, pp. 5027–5034, 2018, doi: 10.1021/acsanm.8b01131.
